Description
Noir is an FPGA-based computer designed for running timeless applications on Linux.
Specifications
- Lattice ECP5 FPGA (LFE5U-45F)
- 44K LUTs
- 4 PLLs
- 256MB (2Gbit) DDR3L DRAM
- 2MB (16Mbit) NOR Flash (via included user-replaceable MMOD module)
- 1 USB host port
- 1 USB-C port for power and configuration
- 1 JTAG header
- MicroSD card slot
- 3.5mm Stereo Audio Line Out (requires FPGA-based delta-sigma DAC)
- DDMI (Differential Data Multiple Interface) port
- Supports DVI over HDMI connector
- 70mm x 50mm board dimensions (revision V0)
Features
- LiteX and Linux support
- USB DFU bootloader
Optional Accessories
Resources
- Example gateware, schematics, documentation and a 3D-printable case are available on GitHub
- Kakao is our Linux distribution for timeless applications
